Machine building
Pressure transmitters are commonly used to control processes in industrial automation systems with hydraulic or pneumatic equipment. They enable accurate monitoring and control of liquid level, flow, and pressure in various technological processes of machine building. PIEZUS manufactures a wide range of transmitters designed to meet the specific requirements of each customer. With a broad selection of mechanical and electrical connections and a wide variety of output signals and pressure ranges, PIEZUS transmitters can be easily integrated into any industrial automated system.
- Precision
pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.1%
Optional: Ex ia, Modbus, HART, field housing, display - Compact line
pressure transmitterRanges: 6 bar up to 600 bar
Accuracy: ±0.5%, ±1%
Sensor: silicon piezoresistive, welded - Digital pressure gaugeRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Sensor: silicon piezoresistive
Display: 4 ½ digits with backlight, min / max value, bargraph, units, 330° rotatable
Battery life: 1 year to 5 years - Electronic pressure switch with PNP outputsRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Switch outputs: PNP (high side), 2 pcs
Analog output: 1...5V (3-wire);
Features: adjustable setpoints and hysteresis - Electronic pressure switch with SPDT relaysRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Relay outputs: SPDT, 2 pcs
Analog output: 4...20 mA (3-wire);
Features: adjustable setpoints and hysteresis - Standard industrial pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Optional: Ex ia, Modbus, HART,
field housing, display - Economy line dual/triple-range pressure transmitterRanges: 6 bar up to 600 bar, up to 3 ranges user selectable
Accuracy: ±0.5%, ±1%
Sensor: silicon piezoresistive, welded
Application
- Pneumatics
- Hydraulics
- Machine tools
- Lubrication systems
- Presses and forming machines
- Weighing technology
- Tank level measurement
- Test benches
