Chemical industry
In most cases, aggressive media (acids, alkalis) and high pressure used in chemical industry reactions. That is why we offer a variety of pressure transmitters with wetted parts made of special chemically resistant materials (stainless steel, plastics and ceramics). Special diaphragm seals and cooling elements make PIEZUS pressure transmitters the best fit for industrial processes with high temperature.
We offer a wide range of transmitters that are robust and heavy duty, including intrinsically safe and flameproof enclosure versions for applications in hazardous locations.
- Small diameter submersible pressure transmitter for aggressive mediaRanges: 6 mH2O up to 200 mH2O
Basic accuracy: ±0.5%
Probe: Ø17 mm plastic
Optional: SS housing Smart pressure transmitter with HART communication
Pressure ranges: 0...15 mbar to 0...600 bar
Accuracy: up to ±0.075% of span
Explosion protection: Ex ia, Ex d- Smart differential
pressure transmitter
with HART communicationRanges: 15 mbar up to 70 bar
Accuracy: up to ±0.075%
Approvals: Ex ia, Ex d - Digital pressure gauge for aggressive/viscous/abrasive mediaRanges: 0.6 bar up to 600 bar
Basic accuracy: ±0.5%
Sensor: ceramic thick film
Pressure port: stainless steel, plastic
Display: 4 ½ digits with backlight, min / max value, bargraph, units, 330° rotatable
Battery life: 1 year to 5 years - Electronic pressure switch with PNP outputs for aggressive/viscous/abrasive mediaRanges: 0.6 bar up to 600 bar, adjustable setpoints and hysteresis
Accuracy: ±0.5%
Switch outputs: PNP (high side), 2 pcs
Sensor: ceramic thick film
Analog output: 1...5V (3-wire);
Pressure port: stainless steel, plastic - Electronic pressure switch with SPDT relays for aggressive/viscous/abrasive mediaRanges: 0.6 bar up to 600 bar, adjustable setpoints and hysteresis
Accuracy: ±0.5%
Relay outputs: SPDT, 2 pcs
Sensor: ceramic thick film
Output: 4...20 mA (3-wire);
Pressure port: stainless steel, plastic - Precision pressure transmitter for aggressive/viscous/abrasive mediaRanges: 40 mbar to 10 bar
Basic accuracy: ±0.25%
Sensor: high precision ceramic capacitive
Pressure port: stainless steel, PVC, PVDF Flush diaphragm
Optional: field housing with/without graphics display - Industrial pressure transmitter for aggressive/viscous/abrasive mediaRanges: 0.6 bar up to 600 bar
Accuracy: ±0.5%
Sensor: ceramic thick film
Pressure port: stainless steel, plastic
Optional: Ex ia, open port, flush diaphragm, field housing, display
Application
- Pump control
- Compressor control
- Process filters monitoring
- Dosing units
- Test benches
- Distillation and storage systems
- Separation systems
