OIL AND GAS (up-, mid- and downstream)
Pressure and level control is critical to many operations and processes in up-, mid- and downstream facilities. Oil and Gas industry standards and regulations impose increasingly strict requirements on metering equipment. When operating in hazardous locations and high-temperature, abrasive and corrosive environments, this equipment must be highly reliable, rugged, and explosion-proof.
PIEZUS designs and manufactures pressure transmitters that ensure safety, accuracy, and long-term reliability—making them an ideal solution for the oil and gas industry. Below is a list of recommended electronic pressure and level transmitters for various Oil and Gas applications.
- Heavy duty
pressure transmitterRanges: 5000 psi up to 15000 psi
Basic accuracy: ±0.5%
Connection: WEKO® 2" (1502)
Optional: Ex ia - Compact explosion proof /
flame proof pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Optional display
Approvals: Ex ia, Ex d - Precision
pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.1%
Optional: Ex ia, Modbus, HART, field housing, display Smart pressure transmitter with HART communication
Pressure ranges: 0...15 mbar to 0...600 bar
Accuracy: up to ±0.075% of span
Explosion protection: Ex ia, Ex d- Smart differential
pressure transmitter
with HART communicationRanges: 15 mbar up to 70 bar
Accuracy: up to ±0.075%
Approvals: Ex ia, Ex d - Ultra small diameter submersible pressure transmitterRanges: 6 mH2O up to 250 mH2O
Basic accuracy: ±0.25%
Probe: Ø17 mm
Optional: Ex ia - Small diameter submersible pressure transmitterRanges: 1 mH2O up to 250 mH2O
Basic accuracy: ±0.25%
Probe: Ø21 mm
Optional: Ex ia - Standard industrial pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Optional: Ex ia, Modbus, HART,
field housing, display - Precision pressure transmitter for aggressive/viscous/abrasive mediaRanges: 40 mbar to 10 bar
Basic accuracy: ±0.25%
Sensor: high precision ceramic capacitive
Pressure port: stainless steel, PVC, PVDF Flush diaphragm
Optional: field housing with/without graphics display - Industrial pressure transmitter for aggressive/viscous/abrasive mediaRanges: 0.6 bar up to 600 bar
Accuracy: ±0.5%
Sensor: ceramic thick film
Pressure port: stainless steel, plastic
Optional: Ex ia, open port, flush diaphragm, field housing, display - Standard submersible pressure transmitterRanges: 1 mH2O up to 250 mH2O
Basic accuracy: ±0.25%
Probe: Ø27 mm
Optional: Ex ia, HART, Modbus, Pt100
UPSTREAM:
-Drilling rig
-Mud tank
-Water tank
-Choke manifold
-Blender units
-Hydration unit
-Sucker rod pump system
-Progressive cavity pumps
-Plunger lift system
MIDSTREAM
-Oil and gas pipelines
-Oil and gas storage tanks
-Oil and gas terminals
-LNG pipelines
-LNG terminal & regasification
-LNG liquefaction trains
-LNG carriers
-Natural gas distribution
DOWNSTREAM
-Crude oil refinery units
-Alkylation units
-Hydrocracking units
-Hydrotreating units
-Isomerisation
-Amine units
-Hydrogen units
