Power generation
PIEZUS pressure and level measuring instruments are used across all areas of power generation: in coal power plants, gas power plants and hydroelectric facilities, as well as cogeneration and peak-load plants such as gas turbine power plants. PIEZUS pressure transmitters can be used for monitoring oil levels in transformers and generators and control compressors, pumps, pipelines, and gas systems at power generation facilities. PIEZUS pressure, level and flow measurement instruments application in all these areas results in a safer industrial environment.
- Compact explosion proof /
flame proof pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Optional display
Approvals: Ex ia, Ex d Smart pressure transmitter with HART communication
Pressure ranges: 0...15 mbar to 0...600 bar
Accuracy: up to ±0.075% of span
Explosion protection: Ex ia, Ex d- Smart differential
pressure transmitter
with HART communicationRanges: 15 mbar up to 70 bar
Accuracy: up to ±0.075%
Approvals: Ex ia, Ex d - Standard industrial pressure transmitterRanges: 40 mbar up to 600 bar
Basic accuracy: ±0.25%
Optional: Ex ia, Modbus, HART,
field housing, display - Economy line dual/triple-range pressure transmitterRanges: 6 bar up to 600 bar, up to 3 ranges user selectable
Accuracy: ±0.5%, ±1%
Sensor: silicon piezoresistive, welded - Industrial differential pressure transmitterRanges: 100 mbar up to 25 bar
Wet/Wet true differential
Accuracy: up to ±0.25%
Optional: Ex ia, Modbus, HART - Standard submersible pressure transmitterRanges: 1 mH2O up to 250 mH2O
Basic accuracy: ±0.25%
Probe: Ø27 mm
Optional: Ex ia, HART, Modbus, Pt100
Application
- Pump control
- Pipe lines control
- Level control systems
- Flow metering systems
- Gas systems control
