APZ 2410

$129
Economy line dual-range pressure transmitter

Features

Ranges: 1 bar up to 160 bar
Number of ranges: up to 2, user-selectable via ZCON 100*
Pressure type: gauge
Accuracy: ±1% FS of the highest chosen range
Output: 4...20 mA / 2 wire
Sensor: ceramic thick film
Pressure port: G1/2ˮ; G1/4ˮ; 1/2ˮ NPT; 1/4ˮ NPT; M20x1.5 etc.
Media temperatures: -25...+135 °C
Ambient temperatures: -40...+85 °C
Improved overpressure capability comparing to model APZ 2412

(*) ZCON 100 configurator is sold separately and provides
ZERO TRIM and RANGE SWITCHING features

Description

APZ 2410 economy line pressure transmitters feature up to two pressure ranges selectable by the user via ZCON 100 configurator tool, allowing customers to have reduced inventory of spare instruments. Based on a monolythic ceramic measuring cell, highly resistive to abrasive and aggressive* media, APZ 2410 is a good fit for the applications where hydraulic shocks (water hammer) are not present. APZ 2410 feature improved overpressure capability as compared to model APZ 2412, which offers improved accuracy.

(*) please consult the manufacturer for particular media compatibility

Code configurator

Order code:

  • -DZ 10
    DZ 10
    Pressure snubber
    Pressure range: up to 700 bar
    Operation principle: throttling
    Temperature range: up to +250 °C
    Housing material: stainless steel
  • -ZCON 100
    ZCON 100
    -ZCON 100
    Zero trim and range selection device
    Ranges: selection of up to 3 ranges, zero trim
    Supported transmitters: multi-range
    Power: 4xAA batteries
  • -ANZ 200
    ANZ 200
    -ANZ 200
    Plug-in display for transmitters with 4-20 mA output
    Compatibility: 4-20 mA transmitters with DIN 43650А connectors
    Display: graphics OLED, rotatable in 2 axis
    Range: -1999...+9999
    Features: min/max values, selectable units and decimal point, archive chart, averaging
    Optional: PNP (high side) switch output
Mechanical connection Electrical connection Model file
G 1/2" EN 837AMP superseal 3-pinAPZ2410_G1'2EN_AMP.step
G 1/2" EN 837Cable Gland with cable (lenght by request)APZ2410_G1'2EN_CableGland#2.step
G 1/2" EN 837DIN 43650 AAPZ2410_G1'2EN_DIN43650A.step
G 1/2" EN 837DIN 43650 CAPZ2410_G1'2EN_DIN43650C.step
G 1/2" EN 837M12x1 straightAPZ2410_G1'2EN_M12x1-straight.step
G 1/2" EN 837PackardAPZ2410_G1'2EN_Packard.step
G 1/4" DIN 3852AMP superseal 3-pinAPZ2410_G1'4DIN_AMP.step
G 1/4" DIN 3852Cable Gland with cable (lenght by request)APZ2410_G1'4DIN_CableGland#2.step
G 1/4" DIN 3852DIN 43650 AAPZ2410_G1'4DIN_DIN43650A.step
G 1/4" DIN 3852DIN 43650 CAPZ2410_G1'4DIN_DIN43650C.step
G 1/4" DIN 3852M12x1 straightAPZ2410_G1'4DIN_M12x1-straight.step
G 1/4" DIN 3852PackardAPZ2410_G1'4DIN_Packard.step
G 1/4" EN 837AMP superseal 3-pinAPZ2410_G1'4EN_AMP.step
G 1/4" EN 837Cable Gland with cable (lenght by request)APZ2410_G1'4EN_CableGland#2.step
G 1/4" EN 837DIN 43650 AAPZ2410_G1'4EN_DIN43650A.step
G 1/4" EN 837DIN 43650 CAPZ2410_G1'4EN_DIN43650C.step
G 1/4" EN 837M12x1 straightAPZ2410_G1'4EN_M12x1-straight.step
G 1/4" EN 837PackardAPZ2410_G1'4EN_Packard.step
M12x1 DIN 3852AMP superseal 3-pinAPZ2410_M12x1DIN_AMP.step
M12x1 DIN 3852Cable Gland with cable (lenght by request)APZ2410_M12x1DIN_CableGland#2.step
M12x1 DIN 3852DIN 43650 AAPZ2410_M12x1DIN_DIN43650A.step
M12x1 DIN 3852DIN 43650 CAPZ2410_M12x1DIN_DIN43650C.step
M12x1 DIN 3852M12x1 straightAPZ2410_M12x1DIN_M12x1-straight.step
M12x1 DIN 3852PackardAPZ2410_M12x1DIN_Packard.step
M20x1,5 EN 837AMP superseal 3-pinAPZ2410_M20x1,5EN_AMP.step
M20x1,5 EN 837Cable Gland with cable (lenght by request)APZ2410_M20x1,5EN_CableGland#2.step
M20x1,5 EN 837DIN 43650 AAPZ2410_M20x1,5EN_DIN43650A.step
M20x1,5 EN 837DIN 43650 CAPZ2410_M20x1,5EN_DIN43650C.step
M20x1,5 EN 837M12x1 straightAPZ2410_M20x1,5EN_M12x1-straight.step
M20x1,5 EN 837PackardAPZ2410_M20x1,5EN_Packard.step
M14x1,5 DIN 3852AMP superseal 3-pinAPZ2410_M14x1,5DIN_AMP.step
M14x1,5 DIN 3852Cable Gland with cable (lenght by request)APZ2410_M14x1,5DIN_CableGland#2.step
M14x1,5 DIN 3852DIN 43650 AAPZ2410_M14x1,5DIN_DIN43650A.step
M14x1,5 DIN 3852DIN 43650 CAPZ2410_M14x1,5DIN_DIN43650C.step
M14x1,5 DIN 3852M12x1 straightAPZ2410_M14x1,5DIN_M12x1-straight.step
M14x1,5 DIN 3852PackardAPZ2410_M14x1,5DIN_Packard.step
M16x1,5 DIN 3852AMP superseal 3-pinAPZ2410_M16x1,5DIN_AMP.step
M16x1,5 DIN 3852Cable Gland with cable (lenght by request)APZ2410_M16x1,5DIN_CableGland#2.step
M16x1,5 DIN 3852DIN 43650 AAPZ2410_M16x1,5DIN_DIN43650A.step
M16x1,5 DIN 3852DIN 43650 CAPZ2410_M16x1,5DIN_DIN43650C.step
M16x1,5 DIN 3852M12x1 straightAPZ2410_M16x1,5DIN_M12x1-straight.step
M16x1,5 DIN 3852PackardAPZ2410_M16x1,5DIN_Packard.step
NPT 1/2"AMP superseal 3-pinAPZ2410_NPT1'2_AMP.step
NPT 1/2"Cable Gland with cable (lenght by request)APZ2410_NPT1'2_CableGland#2.step
NPT 1/2"DIN 43650 AAPZ2410_NPT1'2_DIN43650A.step
NPT 1/2"DIN 43650 CAPZ2410_NPT1'2_DIN43650C.step
NPT 1/2"M12x1 straightAPZ2410_NPT1'2_M12x1-straight.step
NPT 1/2"PackardAPZ2410_NPT1'2_Packard.step
NPT 1/4"AMP superseal 3-pinAPZ2410_NPT1'4_AMP.step
NPT 1/4"Cable Gland with cable (lenght by request)APZ2410_NPT1'4_CableGland#2.step
NPT 1/4"DIN 43650 AAPZ2410_NPT1'4_DIN43650A.step
NPT 1/4"DIN 43650 CAPZ2410_NPT1'4_DIN43650C.step
NPT 1/4"M12x1 straightAPZ2410_NPT1'4_M12x1-straight.step
NPT 1/4"PackardAPZ2410_NPT1'4_Packard.step
